JTS SIEM-2T User Manual

3
1
2
7
8
4-3 Accessory
1. IE-1
1 Earphone
2 Silicon Sleeve
3 Cord
4 1/8” Stereo Phone Plug
5 Case
5. Preparing Procedures
5-1 SIEM-2T
1. Set the rubber pad
Four self-adhesive rubber pads are provided to ensure the
stability. They are to be placed on the bottom of the
transmitter.
4
5
4
2. Power Suppty
2. DR-900(Optional)
2. Connect the audio source, such as a mixer.
Connect the mixer output to the XLR /ɑ6.3mm combo
input in the Front panel of SIEM-2T with the AF input
cable.
NOTE: Two balanced XLR /ɑ6.3mm combo inputs are
provided. You may use either one or both for a stereo source.
Also, two balanced
ɑ6.3mm loop out connectors are provided
for multiple systems application.
(Figure A / P9)

JTS SIEM-2T Specifications

General

Brand	JTS
Model	SIEM-2T
Category	Microphone system
Language	English
