2. Connect with the earphone IE-1
(1) Plug the earphone into the jack of the receiver.
(Figure 1)
(2) Make sure the volume is at low level to avoid injury
to your ears.
(3) Insert earphones into your ear at a correct position.
(Figure2)
(4) Check if the silicon sleeve is suitable for your ear. If
not, replace with other sizes of sleeves for comfort
and best isolation. (Figure 3)
(5) Make sure correct channels are chosen. The letter
“R” and “L” on the earphones indicate the right and
left ear respectively.
5-3 Optional Accessory
1. DR-900/RP-900 Rack Mount Kit
Rack mount kit is available to install the half rack
transmitter into a standard EIA rack.
Figure 3
Figure 1
Figure 2
R
L
