– 104 –
8-4) Feeding is inappropriate. 4-A) The parallel level of the feed Replace the current feed dog with new one.
dog is inappropriate.
4-B) The feed dog is aslant mounted. Mount the feed dog appropriately.
4-C) The feeder bar has a backlash Eliminate the backlash in the state of slightly pressing the
in the right-left direction top, bottom, and horizontal feeder bar pins.
8-5) Pressing is inappropriate. 5-A) The presser is floating. Readjust the position of the presser bar holder.
5-B) The parallel level of the presser Replace the presser, or loosen the presser bar holding
is inappropriate. screw and correct the foot bend.
5-C) The pressure is too low. Increase the pressure of the presser.
8-6) Threading is inappropriate. 6-A) Threading of the needle thread Correct threading.
is improper.
6-B) The needle bar thread guide is Try using B1418227T00 or B1418552A00.
defective.
9. Material breakage 9-1) The needle is defective. 1-A) The needle heat is too high. Use silicon.
1-B) The needle is too thick. Use a needle as thin as possible.
1-C) The needle tip is blunt. Replace the needle.
1-D) The shape of the needle tip is Use a ballpoint needle. (KN, S, J, B, U, Y, etc.)
inappropriate.
(different needle type)
9-2) The speed is too high. Reduce the speed. (prevention of needle heat)
9-3) The material is excessively tense. 3-A) The needle hole of the throat Use a throat plate with a larger needle hole.
plate is too small.
3-B) The pressure is too high. Reduce the pressure as low as possible.
3-C) The height of the presser tooth Lower the height of the presser tooth as low as possible.
is too high.
9-4) The room humidity is too low. Keep the humidity at approx. 65% to prevent needle heat,
electrification, and friction.
9-5) The feeding pitch is too small. Increase the feeding pitch as large as possible.
Trouble Case (1) Case (2) Check and Corrective measures
From the previous page
To Next Page
