JUKI DDL-9000B-SH - Bobbin Insertion; Bobbin Case with Idling Prevention Spring

– 12 –
(5) Bobbin insertion
1) Bobbin case with idling prevention spring
(Drawing is for 40000264.)
B
A
C
o For the bobbin case with idling prevention spring
(1)
(2)
(3)
(4)
Ear
Change the height.
0.3
±
0.2mm
Bobbin revolution
Standard Adjustment
