– 9 –
・
Display PCB
・
Power PCB
Connector No. Destination Check
CN1 POWER SW AC input
CN2 POWER_SUPPLY_RELAY_LEAD_WIRE 1-2PIN 29V, 4-5PIN GND(FG)
マイコン基板 CN19に接続
マイコン基板 CN19に接続
HZL-F600 HZL-F400 / F300
To be connected to CN19
of microcomputer PCB
To be connected to CN19
of microcomputer PCB
CN2
CN1
