– 29 –
6-19 Presser foot lifting
6-19-1 Position of the presser foot lifting motor
Remove the
t
op cover, the spool cover and the front panel.
Adjustmentprocedure
1.Loosenthemotorbracketsetscrew.
2.Removethebacklashfromthepresserfootpressurelevergearandthepresserfootliftingleverintermedi-
ate gear (reduction gear). Then, tighten the setscrew.
Presser foot pressure lever gear
Setscrew
Presser foot lifting
lever intermediate gear
(reduction gear)
