- 13 -
1) Con๎rm that step 1 is displayed on the panel. Now, set the number of stitches to 20 using switches
2
and
3
.
2) Set the feeding direction to the normal direction using switches
4
and
5
.
3) Set the stop state of the sewing machine to the needle-down stop mode using switches
8
and
9
.
4) Set the position of the presser foot, when the sewing machine stops, to the upper stop position using
switches
8
and
9
.
(If you want to specify, In particular, the length of time during which the presser foot Is raised, set It as
desired using switches
!0
and
!1
. In the Initial state, the length of time Is 60 seconds. Possible setting
range of the time during which the presser foot Is raised : 0.1 sec. to 99.9 sec.)
If the number of stitches is set to 0 stitch or the stop-state of the sewing machine is set to the auto-
matic thread trimming mode , the machine will not proceed to the subsequent operation step.
[Step 2]
5) Press switch
!2
once to display step 2.
6) Set the number of stitches to 10 using switches
2
and
3
.
[Step 3]
7) Set the feeding direction to the normal direction, the stop-state of the sewing machine to the needle-
down stop mode and the position of the presser foot to the upper stop position as in the case of step 1.
8) Press switch
!2
once to display step 3.
9) Set the number of stitches to 20 using switches
2
and
3
.
10) Set the feeding direction to the normal direction, the stop state of the sewing machine to the needle-
down stop mode and the position of the presser foot to the upper stop position as in the case of steps 1
and 2.
Settings done by switches
8
,
9
,
!0
and
!1
are only available under the setting where the auto-lifter
can be used (i.e., FL ON).
3
!2
2
!2
2
3
To Next Page
