- 39 -
There are the following error codes in this device. These error codes interlock (or limit function) and inform
the problem so that the problem is not enlarged when any problem is discovered. When you request our
service, please conrm the error codes.
22-1. Error code list (Error display in panel)
No. Description of error detected Cause of occurrence expected Items to be checked
Media cover open • Cover of the slot of media is open. • Close the cover.
E000 Execution of data initialization
(This is not the error.)
When the machine head is changed.
When the initialization operation is executed
E003 Disconnection of
synchronizer connector
When position detection signal is not input
from the sewing machine head synchronizer.
When the synchronizer has broken.
Belt is loose.
Machine head is not proper.
Motor pulley is not proper.
Check the synchronizer connector (CN33)
for loose connection and disconnection.
Check whether the synchronizer cord has
broken since the cord is caught in the
machine head.
Check the belt tension.
Check the setting of the machine head.
Check the setting of the motor pulley.
E004 Synchronizer lower position
sensor failure
E005 Synchronizer upper position
sensor failure
E007 Overload of motor When the machine head is locked.
When sewing extra-heavy material beyond
the guarantee of the machine head.
When the motor does not run.
Motor or driver is broken.
Check whether the thread has been
entangled in the motor pulley.
Check the motor output connector (4P) for
loose connection and disconnection.
Check whether there is any holdup when
turning the motor by hand.
E011 Media is not inserted. Media is not inserted. Turn the power OFF and check the media.
E012 Read error Data of media cannot be read. Turn the power OFF and check the media.
E013 Write error Data of media cannot be written. Turn the power OFF and check the media.
E014 Write protect Media is in the state of writing prohibition. Turn the power OFF and check the media.
E015 Format error Formatting cannot be performed. Turn the power OFF and check the media.
E016 External media capacity over Capacity of media is short. Turn the power OFF and check the media.
E019 File size over File is too large. Turn the power OFF and check the media.
E032 File interchangeability error There is no interchangeability of le. Turn the power OFF and check the media.
E070 Slip of belt When the machine head is locked.
Belt is loose.
Check whether there is any holdup when
turning the motor by hand.
Check the belt tension.
E071 Disconnection of motor
output connector
Disconnection of motor connector Check the motor output connector for loose
connection and disconnection.
E072 Overload of motor at the time
of thread trimming motion
Same as E007 Same as E007
E220 Grease-up warning When the predetermined number of stitches
has been reached.
Replenish the specied places with grease
and reset.
(For the details, refer to the data of the
machine head.)
E221 Grease-up error When the predetermined number of stitches
has been reached and the sewing is not
possible.
Replenish the specied places with grease
and reset.
(For the details, refer to the data of the
machine head.)
E302 Fall detection switch failure
(When the safety switch
works)
When fall detection switch is input in the
state that the power is turned ON.
Check whether the machine head is tilted
without turning OFF the power switch (sewing
machine operation is prohibited for safety
sake).
Check whether the fall detection switch cord
is caught in the sewing machine or the like.
Check whether the fall detection switch lever
is caught in something.
Check whether the contact of the tilt
detection switch lever with the machine table
is inadequate. (The table has a dent or the
mounting location of the bed strut is too far)
