KE2000 Installation Manual
19
6-2-2.Detaching the FMLA head Z-axis fixing parts
Set-up caution tag
1) Remove the SEMS cap screws (SL6042542TN) to detach the spacer (11100500).
2) Make sure that the Z-axis slide bracket moves smoothly in the vertical direction.
WARNING
WARNINGWARNING
WARNING
To prevent the body from injury which can be caused by
accidental activation of the machine , cut off the power to
the machine before starting to work.
図６－２－２－１
