– 17 –
1) To raise the sewing machine, rstly push feed
base ❷ away from you (in the direction of the
arrow), then insert at-blade screwdriver ❹ into
bottom-cover opening tool slot ❸, turn it counter-
clockwise to release the sewing machine up/down
lock ❺.
2) Turn at-blade screwdriver ❹ to keep the lock
in the released state, and slightly lift the sewing
machine by holding it by rib ❶ located on the front
side of the bed.
3) Carefully remove at-blade screwdriver ❹. Hold
ribs ❶ located on the front side of the bed with
your both hands to slowly lift the sewing machine
to the 1st step of hinge stopper ❻.
At this time, do not hold feed base ❷ and feed
guide shaft ❽.
4) Check to be sure that hinge stopper ❻ is locked
by support shaft ❼. Then, take hands off the ribs.
5) To raise the sewing machine to the 1st to 3rd steps
of the hinge stopper, hold ribs ❶ located on the
front side of the bed with your both hands to slowly
lift it to the required step of the hinge stopper.
❷
❶
❹
❻
❼
❽
❷
❸
❺
To Next Page
