– 22 –
!4
Holding time of lifting presser foot (Function setting No. 47)
Solenoid type presser foot lifter (No. 46 0) can adjust the holding time control of lifting presser foot.
This function automatically lowers the presser foot when the time set with the setting No. 47 has passed
after lifting the presser foot.
When the pneumatic type presser foot lifter (No. 46 1) is selected, the holding time control of lifting presser
foot is limitless regardless of the set value.
Setting range
10 to 600 sec <10 / sec>
3
Compensation of off-timing of solenoid for reverse feed stitching at the end of sewing (Function setting No. 53)
Off-timing of solenoid for reverse feed stitching at the start of sewing can be compensated by the unit of angle.
360˚
180˚
0˚
–180˚
–360˚
!5
Compensation of timing of the solenoid for reverse feed stitching (Function setting No. 51 to 53)
W hen the normal and reverse feed stitches are not uniform under the automatic reverse feed stitching action,
this function can change the ON / OFF timing of the solenoid for back tack and compensate the timing.
1
Compensation of on-timing of solenoid for reverse feed stitching at the start of sewing (Function setting No. 51)
On-timing of solenoid for reverse feed stitching at the start of sewing can be compensated by the unit of angle.
* When the point
before 1 stitch is
regardedas0˚,
compensation is
possibleby360˚
(1 stitch) in front
and in the rear.
2
Compensation of off-timing of solenoid for reverse feed stitching at the start of sewing (Function setting No. 52)
Off-timing of solenoid for reverse feed stitching at the start of sewing can be compensated by the unit of angle.
360˚
180˚
0˚
–180˚
–360˚
–360˚
–180˚
0˚
180˚
360˚
Adjusting range
– 36 to 36 <1 / 10˚>
Adjusting range
– 36 to 36 <1 / 10˚>
Set value Compensation
angle
Number of stitches of
compensation
– 36 – 360˚ – 1
– 18 – 180˚ – 0.5
0 0˚ 0
18 180˚ 0.5
36 360˚ 1
Adjusting range
– 36 to 36 <1 / 10˚>
!3
Number of rotation of one-shot stitching (Function setting No. 38)
This function can set, by the pedal operation of one time, the sewing speed of one-shot stitching when the
sewing machine continues stitching until completing the number of stitches specied or detecting the mate-
rial end.
Setting range
150 to MAX. rpm. <50 / rpm>
(Caution) 1. Setting of one-shot stitching is made by the operation panel of the CP-160/CP-170.
2. The max. number of rotation of one-shot stitching is limited by the model of the sewing ma
-
chine head.
Set value Compensation
angle
Number of stitches of
compensation
– 36 – 360˚ – 1
– 18 – 180˚ – 0.5
0 0˚ 0
18 180˚ 0.5
36 360˚ 1
Set value Compensation
angle
Number of stitches of
compensation
– 36 – 360˚ – 1
– 18 – 180˚ – 0.5
0 0˚ 0
18 180˚ 0.5
36 360˚ 1
4 7
6 0
3 8
2 5 0 0
5 1
1 0
5 3
1 8
5 2
1 6
