8) Close cover
3
and fix the cover by tightening
screw
B
with a screwdriver.
(Caution) Take care not to allow the cord to be
caught under cover
3
.
3
B
9) Connect connector 4P
!7
to connector
!
8
locat
ed
on the side of the box.
10) Connect motor
outpu
t cord
!9
of the power switch
to connector
@0
.
Connect motor output cord
@1
to connector
@2
locat-
ed on the side of the box.
CE 1ø 230V
AC
220V-240V
Installing power switch
Connect power supply cord to the power switch.
[CEspecications]
Single phase 230V : Power supply cords :
Brown
,
Blue
,
and green/yellow (ground wire)
Brown
Blue
Green / Yellow
(ground wire)
[ForCEspecicationsonly]
@1
@2
!8
@0
!7
!9
