– 31 –
ENGLISH
147
Alternate
up/down initial
output
Sets the status of the alternate up/down output upon turning the
power on to either ON or OFF
0: The previous power-off state is restored
1: OFF is output
2: ON is output
0 to 2to 2
1 4 7
0
44
148
2-pitch (2-stitch
length) output
during reverse
feed stitching at
beginning/end
of sewing
Carries out 2-pitch output during reverse feed stitching at the
beginning and end of sewing
0 : The function is in the OFF state
1 : The function is in the ON state
0/1
1 4 8
0
44
149
2-pitch inverted
output during
alternate up/
down output
Sets the inverted output of 2-pitch output is carried out or not in
synchronism with alternate up/down output
0 : The function is in the OFF state
1 : The function is in the ON state
0/1
1 4 9
0
44
150
2-pitch initial
output
Selects the status of the 2-pitch output upon turning the power
on between ON and OFF
0 : The previous power-off state is restored
1 : OFF is output
2 : ON is output
0 to 2to 2
1 5 0
0
44
151
Pause and
stitch alignment
function
Temporarily stops at every corner of the sewing pattern at the
beginning and end of sewing and during overlapped stitching
0 : The function is in the OFF state
1 : The function is in the ON state
0/1
1 5 1
0
44
154
Condensation
stitching
function for
beginning/end
of sewing
Enabled when the SC-922 is used in combination with the ma-
chine head provided with condensation stitching function for
thread trimming leaving shorter thread on the material
The sewing machine performs condensation stitching at the be-
ginning and end of sewing
(Condensation stitching is performed instead of automatic re-
verse feed stitching.)
0 : The function is in the OFF state
1 : The function is in the ON state
0/1
1 5 4
0
44
155
Setting of the
position of
carrying out
automatic
presser foot
lifting at neutral
position of pedal
Automatic presser foot lifting at neutral position of pedal is car-
ried out only when the sewing machine stops with its needle
down.
0 : The function of automatic presser foot lifting at neutral po-
sition of pedal is enabled at all times
1 : The automatic presser foot lifting at neutral position of
pedal is only enabled when the sewing machine stops
with its needle down
(Disabled when No. 93 Needle up/down correction switch add-
ing function setting is "2.")
0/1
1 5 5
0
38
156
Needle thread
grasping
function
Enabled when the SC-922 is used in combination with the ma-
chine head provided with the needle thread grasping function
Selects the status of the needle thread grasping function
0 : ON/OFF with the operation enabling switch
1 : Disables the needle thread grasping function
2 : Forcibly enables the needle thread grasping function
0 to 2to 2
1 5 6
0
44
158
Condensation
stitching
function during
thread trimming
Enabled when the SC-922 is used in combination with the ma-
chine head provided with condensation stitch function for thread
trimming leaving shorter thread on the material
Selects whether or not the condensation stitch for thread trim-
ming leaving shorter thread on the material is output
0 : The function is in the OFF state
1 : The function is in the ON state
0/1
1 5 8
0
163
Alternate
up/down speed
limitation enable
Limits the maximum sewing speed by means of the alternate
up/down amount
Refer to the Engineer's Manual for details.
0/1
1 6 3
0
164
Standing
operation pedal
input high-
speed switch
function
Runs the sewing machine at a high speed whenever the stand-
ing operation pedal input exists
0 : The function is in the OFF state
1 : The function is in the ON state
0/1
1 6 4
0
167
With/without
bobbin thread
remaining
amount
detection
Bobbin thread remaining amount detecting device is used.
However, the bobbin thread counter operates normally regard-
less of the setting of the bobbin thread remaining amount detec-
tion.
0 : The function is in the OFF state
1 : The function is in the ON state
0/1
1 6 7
1
45
168
Bobbin thread
remaining
amount
detecting
function
Sets the function of the bobbin thread remaining amount detect-
ing device
Carry out setting referring to the Instruction Manual for the bob-
bin thread remaining amount detecting device.
0/1
1 6 8
0
45
174 Thread tension
changeover
function
Tension release function on one side is turned ON/OFF in con-
junction with other output.
0 : Disabled
1 : Turned OFF when alternate up/down output is turned ON,
and turned ON when alternate up/down output is turned
OFF
2 : Turned OFF upon alternate up/down output, and turned
ON upon thread trimming
0
toto
2
1 7 4
0
No
Item Description
Setting range
Indication of function setting
Ref. page
* Do not change the set values with asterisk (
*
) mark as they are functions for maintenance. If the standard set value set at the
time of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
If it is necessary to change the set value, please purchase the Engineer’s Manual and follow the instructions.
