Recirculating Cooler FL601
Circulating pump:
discharge, max.at 0 bar l/min 23
pressure, max. at 0 Liters
bar 1.0
bar -----
Filling level indicator sight glass
Filling volume from ... to Liters 5.5 ... 8
Dimensions (WxLxH) cm 32x50x60
Weight
kg 48
Ambient temperature range °C 5 ... 40
Return flow temperature °C 80 max.
IP class according to IEC 60 529 IP 21
Mains power connection 230 V/50 Hz V/ Hz 207-253 / 50
Current input at 230 V A 4.6
Mains power connection 208 - 220 V/60 Hz V/ Hz 197 - 242 / 60
Current input at 208V / 220 V A 5.0
Mains power connection 115 V/60 Hz V/ Hz 103-127 / 60
Current input at 115 V A 9.1
All measurements have been carried out at: rated voltage and frequency,
ambient temperature: 20 °C
