JUMO DICON touch Manual

4 The GSDML file
12
Cyclical IO data, DeviceStatusBlock
IO item Type Bit item Bit ad-
dress
Explanation
Sub-module 1
Status bits 1 USINT Collective alarm 0 Internal signals of the JUMO DICON touch
 See operating manual, chapter on digital
selector configuration
Collective alarm ac-
knowledged
1
Memory alarm 2
Pre-alarm battery 3
Battery empty 4
Logon 5
USB inserted 6
Temperature in °F 7
Status bits 2 USINT – 0 Not used
–1
–2
–3
–4
–5
–6
–7
Status bits 3 USINT Manual mode, Control-
ler 1
0 Internal signals of the JUMO DICON touch
 See operating manual, chapter on digital
selector configuration
Tune controller 1 1
Manual mode, Control-
ler 2
2
Tune controller 2 3
– 4 Not used
–5
–6
–7
Status bits 4 USINT – 0
–1
–2
–3
–4
–5
–6
–7
