JUMO DICON touch Manual

13
4 The GSDML file
Encoder status USINT – 0 Internal signals of the JUMO DICON touch
 See operating manual, chapter on digital
selector configuration
Programstopsignal 1
Basic status 2
Pre-programming 3
Manual operation mode 4
Programautosignal 5
Program end signal 6
Tolerancebandsignal 7
Dummy USINT – 0 Fill byte (no function; used to satisfy require-
ments for certain data structures)
–1
–2
–3
–4
–5
–6
–7
Operating contacts UINT Operating contact 1 0 Internal signals of the JUMO DICON touch
 See operating manual, chapter on digital
selector configuration
Operating contact 2 1
Operating contact 3 2
Operating contact 4 3
Operating contact 5 4
Operating contact 6 5
Operating contact 7 6
Control contact 8 7
–8
–9
–10
–11
–12
–13
–14
–15
Cyclical IO data, DeviceStatusBlock
IO item Type Bit item Bit ad-
dress
Explanation
