JUMO DICON touch Manual

15
4 The GSDML file
Binary values UDINT Digital input IN1 0 Internal signals of the JUMO DICON touch
 See operating manual, chapter on digital
selector configuration
Digital input IN2 1
Digital input IN3 2
Digital input IN4 3
Digital input IN5 4
Digital input IN6 5
Digital input IN7 6
Digital output OUT1 7
Digital output OUT2 8
Digital output OUT3 9
Digital output OUT4 10
Digital output OUT5 11
Digital output OUT6 12
Digital output OUT7 13
Digital output OUT8 14
Digital output OUT9 15
Digital output OUT10 16
Digital output OUT11 17
Digital output OUT12 18
Limit value output 1 19
Limit value output 2 20
Limit value output 3 21
Limit value output 4 22
Limit value output 5 23
Limit value output 6 24
Limit value output 7 25
Limit value output 8 26
Limit value output 9 27
Limit value output 10 28
Limit value output 11 29
Limit value output 12 30
Limit value output 13 31
Empty byte USINT – Not used
Cyclical IO data, DeviceStatusBlock
IO item Type Bit item Bit ad-
dress
Explanation
