JUMO diraTRON 108 Brief Instructions

5 Technical data
28
5.5 Interfaces
5.6 Display
5.7 Electrical data
USB device
Connector type Micro-B (socket)
Standard Low-Speed, Full-Speed
Max. cable length 5 m
RS485
Baud rate 9600, 19200, 38400, 115200
Data format 8/1n, 8/1e, 8/1o, 8/2n
Protocol Modbus RTU as slave
18-segment LCD displays
Digit height Upper display: Lower display:
Type 702110 (format 132) 7.2 mm 3.8 mm
Type 702111 (format 116) 12.3 mm 5.9 mm
Type 702112 (format 108H) 11.5 mm 8.5 mm
Type 702113 (format 108Q) 16.5 mm 9 mm
Type 702114 (format 104) 24.8 mm 12 mm
Color Upper display: white; lower display: green
Places, including decimal places Upper display: 4; lower display: 4 (5 for type 702110, 8 for type 702111)
Decimal places 0, 1, 2, 3 or automatic (configurable)
Pixel matrix LCD display (only for types 702112, 702113, and 702114)
Pixel fields
Type 702112 (format 108H) 2 rows each with 9 pixel fields
Type 702113 (format 108Q) 2 rows each with 8 pixel fields
Type 702114 (format 104) 2 rows each with 11 pixel fields
Number of pixels per field 8 x 5
Color White
Voltage supply AC 110 to 240 V +10/-15 %, 48 to 63 Hz
AC/DC20to30V, 48to63Hz
Electrical safety According to EN 61010, part 1; overvoltage category II to 300 V mains voltage,
pollution degree 2
Protection rating I with internal isolation from SELV
Power consumption For AC 110 to 240 V: For DC 20 to 30 V:
Type 702110 (format 132) Max. 3.5 W Max. 3.0 W
Type 702111 (format 116) Max. 4.1 W Max. 3.7 W
Types 702112, 702113
(formats 108H, 108Q)
Max. 5.8 W Max. 5.7 W
Type 702114 (format 104) Max. 6.6 W Max. 6.7 W
Electrical connection On the back via spring-cage terminals (Push-In technology)
