JUNCTEK KH-F Series User Manual

JUNCTEK
30
February 8th, 2023;
12418 represents the time as
11:24:18.
Read
all
settin
g
values
:R51
=1,2,
1,
:r51=1,69,2000,1000,2
000,3000,20000,120,5,
3,200,120,90,101,0,0,1
,100,0,10000,1000,20,
20,80,0,4321,2,
1 represents communication
address;
69 represents checksum;
2000 represents overvoltage
protection set to 20.00V;
1000 represents undervoltage
protection set to 10.00V;
2000 represents over-discharge
current protection set to 20.00A;
3000 represents over-charge current
protection set to 30.00A;
20000 represents over-power
protection set to 200.00W;
120 represents over-temperature
protection set to 20
℃
;
5 represents protection recovery
time set to 5s;
3 represents protection delay time
set to 3s;
200 represents preset battery
capacity set to 20.0Ah;
120 represents voltage calibration
fine-tuning with 20 tuning factors;
(100 represents tuning factor 0)
90 represents current calibration
fine-tuning with -10 tuning factors;
(100 represents tuning factor 0)
101 represents temperature
calibration increase by 1℃; (100
represents tuning factor 0)
0 represents undefined function;
0 represents normally open relay
type; (0-normally open relay,
1-normally closed relay)
1 represents current multiplier set to
1; (only applicable to Hall version)
100 represents time fine-tuning
function (undefined);
0 represents data logging enabled;
10000 represents full charge voltage
set to 100.00V;
1000 represents low battery voltage
set to 10.00V;
20 represents full charge current
value set to 20%;
20 represents monitoring time set to
2.0min;
