08.11 EN
52
3.1.2 Operating with two LPG bottles
WARNING!
Visibility is restricted when the truck reverses.
XWhen using two LPG bottles the truck must be fitted with a functional camera
system for reversing.
XExternal mirrors must also be fitted on either side of the truck.
Operating the twin bottle system
NOTE
Use the additional valve (60) on the
bracket (58) to change between gas
supply. You can tell which bottle is
supplying the gas by the gas hose
connection on the valve (55) and the
routing towards the LPG bottles (e.g.
RH side of toggle valve = up, LH side of
toggle valve = down).
Procedure
• Use the lever (61) to change between the top
and bottom LPG bottles.
Replacing the LPG bottles
Procedure
• (see "Using an LPG bottle" on page 50)
Z Replace an empty LPG bottle at the earliest opportunity with a full one.
Switching off the gas supply
Procedure
• Close both shutoff valves on the gas bottles to interrupt the supply of gas.
60
55
55
58
61
