Slow travel / brake pedal
Requirements
– Truck ready for operation, (see
"Preparing the truck for operation" on
page 71).
Procedure
• Apply the slow travel / brake pedal (72)
sensitively.
The Industrial truck moves slowly in the
selected travel direction and allows for
excellent shunting in confined areas.
Rapid lifting is possible at a slow travel
speed.
NOTE
The slow travel / brake pedal can also actuate the drum brakes but this is only
intended as a crawl speed aid. The pedal should not be used as a service brake. This
operating mode can only be used for max. 5 seconds when the engine is running at
high speed.
4.6 Steering
Steering
Procedure
Z Very little steering effort is required; you
should therefore turn the steering wheel
(74) sensitively.
• To negotiate a right-hand bend: Turn
the steering wheel clockwise according
to the required steering radius.
• To negotiate a left-hand bend: Turn the
steering wheel anti-clockwise according
to the required steering radius.
The truck travels in the direction selected.
72
74
