Jungheinrich EKS 314 User Manual

E 5
1005.USA
Guidance systems
“Guidance on” display
not active
“Guidance on” display
active
t
RG
WG
Displays automatic guidance in the aisle:
Rail guidance display
(drive wheel set to forward position)
Indicates that inductive / wire guidance is
activated
“Guidance on” switch RG
WG
Sets the drive wheel to forward position
Activates the alignment
(and frequency selection (for multifrequen-
cy)
Displays “Select Fre-
quency 1” (similar to oth-
er frequencies)
(“Guidance on” sub-
menu)
o
WG
Indicates that guidance is possible via Fre-
quency 1
“Select Frequency 1”
switch (similar to other
frequencies)
Activates guidance through frequency 1
(automatically quits the sub-menu after 1
second)
“Special attachment” dis-
play
o Indicates that the special attachment can
be controlled
“Special
attachment”switch
Activates control of the special attachment,
controlled via the hydraulic control button
t = Standard equipment o = Optional Equipment
RG = Rail guidance WG = Wire / inductive guidance
Symbol Control or Display Function
E 5
1005.USA
Guidance systems
“Guidance on” display
not active
“Guidance on” display
active
t
RG
WG
Displays automatic guidance in the aisle:
Rail guidance display
(drive wheel set to forward position)
Indicates that inductive / wire guidance is
activated
“Guidance on” switch RG
WG
Sets the drive wheel to forward position
Activates the alignment
(and frequency selection (for multifrequen-
cy)
Displays “Select Fre-
quency 1” (similar to oth-
er frequencies)
(“Guidance on” sub-
menu)
o
WG
Indicates that guidance is possible via Fre-
quency 1
“Select Frequency 1”
switch (similar to other
frequencies)
Activates guidance through frequency 1
(automatically quits the sub-menu after 1
second)
“Special attachment” dis-
play
o Indicates that the special attachment can
be controlled
“Special
attachment”switch
Activates control of the special attachment,
controlled via the hydraulic control button
t = Standard equipment o = Optional Equipment
RG = Rail guidance WG = Wire / inductive guidance
Symbol Control or Display Function
