Juniper 200 Series - Console and Modem Ports; Compact Flash Card Slot

The Front Panel
NetScreen-200 Series 5
Console and Modem Ports
The Console port is an RJ-45 serial console port connector, for vt100 terminal emulator
programs to perform local configuration and administration.
The Modem port is an RJ-45 serial console port connector, for establishing remote console
sessions using dialup connections through a 9600 bps modem connected via an RS-232
cable. Dialing into the modem establishes the dialup console connection.
The table below lists the RJ-45 to DB-9 adapter connection definitions. To employ a
standard UART port, both the console and the modem ports use this configuration.
Compact Flash Card Slot
The NetScreen-200 Series supports CompactFlash
™
cards with a variety of memory
capacities. NetScreen has tested SanDisk 96MB and 512MB cards. The NetScreen device
automatically detects the presence of a flash card and records the system log to it.
DB9 Signal Abbreviation DTE DCE RJ-45
1 Data Carrier Detect DCD In Out NC
2 Received Data RD In Out 3
3 Transmitted Data TD Out In 6
4 Data Terminal Ready DTR Out In 7
5 Signal Ground SGND N/A N/A 4
6 Data Set Ready DSR In Out 2
7 Request To Send RTS Out In 8
8 Clear To Send CTS In Out 1
9 Ring Indicator RI In Out NC
