Install the PTX10004 in a Rack
IN THIS SECTION
What’s in the Crate? | 2
What Else Do I Need? | 2
Assemble the Rack-Mount Kit | 3
Mount the PTX10004 on a the Rack and Ground the Chassis | 3
Before you begin the installation, review General Safety Guidelines and Warnings.
What’s in the Crate?
Along with your PTX10004, you’ll also find:
•
A rack-mount kit with:
•
Twelve Phillips flat-head screws, 8-32 x .375 in.
•
Two rear rails
•
A mounting tray
•
A rear safety restraint
•
The EMI front door
•
An accessory kit with:
•
RJ-45 Ethernet cable
•
RJ-45 to DB9 rollover cable
•
Electrostatic discharge (ESD) wrist strap with cable
•
Media kit (flash drives, PCMCIA card adapter)
•
Ground chassis lug, 2-hole, 10-32, 6 AWG
•
Power cord retainer clips, two for each JNP10K-PWR-AC2 power supply
What Else Do I Need?
•
A mechanical lift rated for 250 lb (113.4 kg)
•
4 AWG (21.1 mm²) stranded wire grounding cable rated 75° C or per local electrical code
•
A Phillips (+) screwdriver, number 2 or number 3, depending on the size of your rack-mount screws
•
A number 3 Pozidriv or Phillips (+) screwdriver for the grounding screws
2
