Juniper Day One+ User Manual

•
Eight rack-mount screws
•
Cage nuts and washers, if your rack requires them
Assemble the Rack-Mount Kit
Watch this animation to see how to install the rack-mount kit and follow the steps:
Video: Rack Mount the PTX10004
1. Line up the mounting shelf to the front rack rails.
2. Attach the shelf to the rack using six rack screws.
3. Slide each mounting rail into the mounting tray grooves.
4. Attach the rails to the rack using eight rack screws.
5. Line up the holes in the mounting rail with the holes in the mounting tray.
6. Attach the mounting rails to the mounting shelf using the 12 flat-head screws.
Mount the PTX10004 on a the Rack and Ground the Chassis
Watch this animation to see how to load and install the chassis and follow the steps.
Video: How to Load a PTX10004 into a Rack
3
