Juniper EX4100 Guide

Install the EX4100 and EX4100-F
IN THIS SECTION
What's in the Box? | 5
What Else Do I Need? | 5
Install the EX4100 and EX4100-F Switch in a Rack | 6
What's in the Box?
• EX4100 switch with two preinstalled fan modules and one preinstalled power supply unit or EX4100-F switch with
built-in fans and power supplies
• One AC power cord appropriate for your geographical locaon.
• AC power cord retainer
• Eight preinstalled dust covers for SFP ports
• Four rubber feet
• RJ-45 cable and RJ-45 to DB-9 serial port adapter
What Else Do I Need?
• Someone to help you secure the switch to the rack
• Mounng screws to secure the EX4100 and EX4100-F switch to the rack
• A number two Phillips (+) screwdriver
• A serial-to-USB adapter (if your laptop doesn’t have a serial port)
• An electrostac discharge (ESD) grounding strap
• A management host such as a laptop or desktop PC
• Two M5X10mm screws with washer to secure the grounding lug
• A grounding cable: 8 AWG (2 mm²), minimum 90° C wire, or as permied by the local code, with a Panduit
LCD8-14A-L or equivalent lug aached
5

Juniper EX4100 Specifications

General

Model	EX4100
Category	Switch
Layer	Layer 2/3
Power Consumption	Varies by model and configuration
PoE	Optional
Management	Web UI, CLI, SNMP
Operating Temperature	0°C to 45°C
Input Voltage	100-240V AC
Storage Temperature	-40°C to 70°C
Humidity	5% to 90% non-condensing
DC Power Input	-48V DC
JUNOS OS	Yes
Security Features	ACLs
Layer 2 Features	VLAN, RSTP, MSTP, LACP
Layer 3 Features	Static routing, OSPF
QoS	8 queues per port
