Juniper J-Series Administration Guide

Table 55: Summary of Key RIP Routing Output Fields (continued)
Additional InformationValuesField
Number of RIP routes advertised on the logical
interface.
Routes
advertised
RIP Neighbors
This value is the name of the interface on which RIP
is enabled. The name is set in either of the following
ways:
■
In the J-Web configuration editor, on the
Protocols>RIP>Group> group-name>Neighbor
page
■
In the CLI configuration editor, with the neighbor
neighbor-name statement at the [edit protocols rip
group group-name] level of the configuration
hierarchy
Name of the RIP neighbor.Neighbor
State of the RIP connection: Up or Dn (Down).
State
This value is the configured address of the interface on
which RIP is enabled.
Local source address.Source
Address
This value is the configured address of the immediate
RIP adjacency.
Destination address.Destination
Address
Value of the incoming metric configured for the RIP
neighbor.
In Met
Monitoring DLSw Routing Information
To view DLSw routing information, select Monitor>Routing>DLSw Information,
or enter the following CLI commands:
■
show dlsw capabilities
■
show dlsw circuits
■
show dlsw peers
■
show dlsw reachability
Table 56 on page 121 summarizes key routing information output fields in the DLSw
routing display.
Table 56: Summary of Key DLSw Routing Information Output Fields
Additional InformationValuesField
DLSw Capabilities
IP address of the peer DLSw routerPeer
Numerical value assigned to Juniper Networks.Vendor ID
Using the Monitoring Tools ■ 121
Chapter 7: Monitoring the Router and Routing Operations
