Juniper J-Series Administration Guide

The fields in the display are the same as those displayed by the J-Web ping MPLS
diagnostic tool. For information, see “Ping MPLS Results and Output” on page 222.
Pinging Layer 3 VPNs
Enter the ping mpls l3vpn command with the following syntax. Table 118 on page
234 describes the ping mpls l3vpn command options.
user@host> ping mpls l3vpn prefix prefix-name <l3vpn-name> <bottom-label-ttl>
<exp forwarding-class> <count number> <source source-address> <detail>
To quit the ping mpls l3vpn command, press Ctrl-C.
Alternatively, you can use the J-Web interface. (See “Checking MPLS Connections
from the J-Web Interface” on page 219.)
Table 118: CLI ping mpls l3vpn Command Options
DescriptionOption
Pings the remote host specified by the prefix to verify that the prefix is present in the PE router's
VPN routing and forwarding (VRF) table. This option does not test the connectivity between a
PE router and a CE router.
l3vpn prefix prefix-name
(Optional) Layer 3 VPN name.
l3vpn-name
(Optional) Displays the time-to-live (TTL) value for the bottom label in the MPLS label stack.
bottom-label-ttl
(Optional) Specifies the value of the forwarding class to be used in the MPLS ping packets.
exp forwarding-class
(Optional) Limits the number of ping requests to send. Specify a count from 0 through 1,000,000.
The default value is 5. If you do not specify a count, ping requests are continuously sent until
you press Ctrl-C.
countnumber
(Optional) Uses the source address that you specify, in the ping request packet.
source source-address
(Optional) Displays detailed output about the echo requests sent and received. Detailed output
includes the MPLS labels used for each request and the return codes for each request.
detail
Following is sample output from a ping mpls l3vpn command:
user@host> ping mpls l3vpn vpn1 prefix 10.255.245.122/32
!!!!!
--- lsping statistics ---
5 packets transmitted, 5 packets received, 0% packet loss
The fields in the display are the same as those displayed by the J-Web ping MPLS
diagnostic tool. For information, see “Ping MPLS Results and Output” on page 222.
234 ■ Using CLI Diagnostic Commands
J-series™ Services Router Administration Guide
