NOTE: If the router is not pulled all the way into the rack by the winch
mechanism, grasp the handles on the shipping covers and carefully slide
the router onto the mounting shelf until the front-mounting flanges contact
the rack rails. You must remove the winch bracket to perform this
procedure.
NOTE: There must be a minimum of 45-U of usable rack space when
installing the MX2020 into a 45-U rack.
19. Remove the router transport platform, and set the platform aside.
20. Remove the winch mount and winch strap plate, and set them aside.
21. Insert sixteen mounting screws (eight on each side) into the mounting holes to secure
the router to the rack.
22. Visually inspect the alignment of the router. To verify that the router is installed properly
in the rack, see that all the mounting screws on one side of the rack are aligned with
the mounting screws on the opposite side and the router is level.
23. Reassemble the router transport kit, and set aside.
Copyright © 2015, Juniper Networks, Inc.42
MX2020 3D Universal Edge Router Quick Start
