root> configure
6. Add a password to the root administration user account.
[edit]
root@# set system root-authentication plain-text-password
New password:password
Retype new password:password
7. (Optional) Configure the name of the switch. If the name includes spaces, enclose the name in quotation marks (“ ”).
[edit]
root@# set system host-name host-name
8. Configure the default gateway.
[edit]
root@# set routing-options static route default next-hop address
9. Configure the IP address and prefix length for the switch management interface.
[edit]
root@# set interfaces em0 unit 0 family inet address address/prefix-length
NOTE: The management ports em0 (C0) and em1 (C1) are located on the rear panel of the QFX5120-48Y
switch. The , the management port em0 (MGMT) is located on the front panel of the QFX5120-32C switch.
10. (Optional) Configure the static routes to remote prefixes with access to the management port.
[edit]
root@# set routing-options static route remote-prefix next-hop destination-ip retain no-readvertise
11. Enable Telnet service.
[edit]
root@# set system services telnet
12. Enable SSH service.
[edit]
root@# set system services SSH
13. Commit the configuration to activate it on the switch.
[edit]
14
