Juniper SRX320 Quick Start Guide

NOTE: The mounting kits are not shipped with the device and must be ordered separately.
Table 6: Rack Mount Kits for the SRX320
Rack Mount Kit Without Power
Supply Adapter Tray
Rack Mount Kit With Power Supply
Adapter TrayModel
SRX320-RMK1
Includes:
•
Eight flat-head M3x5mm Phillips
mounting screws
•
Two mounting brackets
SRX320-RMK0
Includes:
•
Twelve flat-head M3x5mm Phillips
mounting screws
•
One mounting bracket
•
One power supply adapter tray and two
adapter stopper brackets
SRX320 (non-PoE
model)
SRX320-P-RMK1
Includes:
•
Eight flat-head M3x5mm Phillips
mounting screws
•
Two mounting brackets
SRX320-P-RMK0
Includes:
•
Thirteen flat-head M3x5mm Phillips
mounting screws
•
One mounting bracket
•
One power supply adapter tray and three
adapter stopper brackets
SRX320 (PoE model)
5

Juniper SRX320 Specifications

General

Firewall throughput	1000 Mbit/s
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	27 W
Heat dissipation	157 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	284700 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2

Weight and Dimensions

Weight	1510 g
Dimensions (WxDxH)	299.9 x 43.9 x 191 mm
