Table 7: LED States
StateLED
•
Solid amber (noncritical alarm).
•
Solid red (critical alarm).
•
Off (no alarms).
ALARM
•
Solid green (operating normally).
•
Solid red (error detected).
STAT
•
Solid green (receiving power).
•
Solid red (power failure).
•
Off (no power).
PWR
•
Solid green (all HA links are available).
•
Solid amber (some HA links are unavailable).
•
Solid red (HA links are not functional).
•
Off (HA is disabled).
HA
•
Green (mini-PIM is present and detected by the device).
•
Off (mini-PIM is not present or not detected by the device).
mPIM1, mPIM2
Configure Root Authentication
To configure the device by using J-Web:
1. Connect one end of the Ethernet cable to any of the network ports numbered 0/1 through 0/6 on the device.
NOTE: The ge-0/0/0 and ge-0/0/7 interfaces (ports 0/0 and 0/7) are WAN interfaces. Do not use these
ports for the initial configuration procedure.
2. Connect the other end of the Ethernet cable to the management device.
9
