Juniper SRX340 How To Set Up

How to Set Up Your SRX300 Services Gateway
2
Gather Configuration Information
Gather information about your network and the configuration settings that you
will use to configure the device.
Required
Device name
Root authentication
Optional
NTP server name or IP address
Licenses
Internet zone
Static IP or Dynamic IP (provided by ISP)
Port number
DMZ
Network IP address
Port number
Internal zone
Zone name
Network IP address
Port number
DHCP server
Security policies
Remote client IP pool range
Source NAT
Internal zones for which source NAT has been added
IP address or hostname
Factory-Default Settings
Security Policies
Source Zone Destination Zone Policy Action
trust untrust permit
trust trust permit
untrust trust deny
NAT Rules
Source Zone Destination Zone Policy Action
trust untrust Source NAT to untrust zone
interface
Interfaces
Port Label Interface Security Zone DHCP State IP Address
0/0 ge-0/0/0 untrust Client Dynamically
assigned
0/1 ge-0/0/1 trust Server 192.168.1.1/24
0/2 ge-0/0/2 trust Server 192.168.2.1/24
0/3 ge-0/0/3 trust Server 192.168.3.1/24
0/4 ge-0/0/4 trust Server 192.168.4.1/24
0/5 ge-0/0/5 trust Server 192.168.5.1/24
Initial Configuration Process
g000
738
Verify the
Settings
Configure
Using Guided/
Default Setup
Log in
to J-Web
Connect the
Management
Device
Power On
the Device
Connect the
Grounding Cable
(Optional)

Juniper SRX340 Specifications

General

Firewall Throughput	3 Gbps
Maximum Concurrent Sessions	256, 000
Memory	4 GB
Redundant Power Supplies	No
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	10% to 90% non-condensing
Storage	8 GB
