Physical 61
Appendix A
Specifications
This appendix provides general system specifications for an SSG 500M Series
device. It includes the following sections:
“Physical” on this page
“Electrical” on page 62
“Environmental Tolerance” on page 62
“Certifications” on page 62
“Connectors” on page 64
Physical
Table 9 provides the physical specifications for an SSG 500M Series device.
Table 9: SSG 500M Series Physical Specifications
Description Value
Chassis
dimensions
3.44 in. (8.74 cm) high
17.44 in. (44.3 cm) wide—19.44 in. (49.38 cm) wide with mounting brackets
attached
21.13 in. (53.66 cm) deep—plus 0.5 in. (1.27 cm) of hardware that protrudes
from the chassis front
Device weight SSG 520M device:
Minimum (no PIMs): 23 lb (10.4 kg)
Maximum (six PIMs): 25.3 lb (11.5 kg)
SSG 550M device:
Minimum (no PIMs and one power supply): 25.5 lb (11.6 kg)
Maximum (six PIMs and two power supplies): 30.7 lb (13.9 kg)
