Juniper T640 - Six-Input DC Power

Figure 26: Connecting a DC Power Cable to a Four-Input 240-A DC Power Supply
g004661
Terminal studsCable lug
Locking
washer
Nut
Replacing a T640 Power Supply Filter Element
To replace a power supply filter element (see Figure 27):
1. Grasp the filter cover on the power supply faceplate and pull it straight off the
power supply.
2. Remove the filter element.
3. Install a new filter element.
4. Press the filter cover straight onto the power supply faceplate until all four sides
click into place.
30 ■ Replacing a T640 Power Supply Filter Element
