SPARE PART DATA SHEET – LC 300 D
REV
.
10
30-01-2018
19 / 32
Jurop
SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
T
EL
.
+39
0
434
636811
F
AX
.
+39
0
434
636812
http://www.jurop.it
e-mail: info@jurop.it
LC 300 D
Pos.
Code Description Q.ty Pos.
Code Description Q.ty
1 1401200700 OIL DRIPPER 2 53 4024251000 OIL PUMP CW ROTATION (LC D DX) 1
2 1407200900 WATER PUMP SX (LC D SX) 1 4024251500 OIL PUMP CCW ROTATION (LC D SX) 1
1407200800 WATER PUMP DX (LC D DX) 1 54 4025350019 BELTSPZ 925 1
3 1521506500 ROTOR LC300 D 1 55 4026101301 SCREW TE 8.8 M6X10 ZINC. 2
1521506400 ROTOR LC300 D USA
1
56 4026102806 SCREW TE 8.8 M8X20 ZINC. 7
4 154201TWB0 BELT PROTECTION LC D SX 1 57 4026102807 SCREW TE 8.8 M8X25 ZINC. 16
154201TVB0 BELT PROTECTION LC D DX 1 58 4026102819 SCREW TE 8.8 M8X90 ZINC. 2
5 1601606400 VANE LC300 4 59 4026102908 SCREW TE 8.8 M10X30 ZINC. 2
6 1605500000 HANDLE 1 60 4026103030 SCREW TE 8.8 M12X16 ZINC. 4
7 1608100000 DISTRIBUTOR 1 61 4026120301 SCREW TCEI 8,8 M6X12 4
8 1608501700 CONVEYOR 1 62 4026121305 SCREW TCEI 8,8 M6X16 ZINC. 2
9 1610051700 FLANGE 1 63 4026121405 SCREW TCEI 8.8 M8X20 ZINC. 3
10 1610508200 FLANGE 1 64 4026121710 SCREW TCEI 8.8 M12X35 ZINC. 2
11 1610510800 FLANGE 1 65 4026135414 SCREW S.TESTA 14.9 M8X45 ZINC. 1
12 1610512900 OIL PUMP FLANGE 1 66 4026135504 SCREW S.TESTA 14.9 M10X10 ZINC. 1
13 1610513500 FLANGE 2 67 4026141508 SCREW TE 10.9 M10X30 ZINC. 16
14 161201X4B0 PUMP SUPPORT 1 68 4026171211 SCREW PRIGION. 8,8 M12X80 ZINC. 2
15 1622002600 SHAFT M10 1 69 4026305508 NUT M12 SELFLOCKING 2
16 1623100000 CONVEYOR FLANGE 1 70 4026308005 NUT M8 2
17 1624027500 SPACER 1 71 4026308006 NUT M10 2
18 1624037700 SPACER 2 72 4026350503 WASHER GROWER M6 Q 6
19 1624042800 SPACER 2 73 4026350505 WASHER GROWER M8 Q 6
20 1624202300 4 WAYS SPACER 1 74 4026350508 WASHER GROWER M12 Q 2
21 1627505300 MANIFOLD 1 75 4026350706 WASHER GROWER M8 P 21
22 1642100200 REAR PROTECTION 1 76 4026350708 WASHER GROWER M10 P 4
23 165351TXB0 DRIVEN PULLEY 1 77 4026351504 TOOTHED WASHER M6 2
24 16630D5SB0 LUBRICATION LINE 1 78 4026351506 TOOTHED WASHER M10 16
25 16630D5PB0 LUBRICATION LINE 1 79 4026357005 WASHER M8 2
16630D5IB0 LUBRICATION LINE USA 1 80 4026357006 WASHER M10 4
26 166301SZB0 LUBRICATION LINE 1 81 4026357007 WASHER M12 2
27 166301T0B0 LUBRICATION LINE 1 82 4026359001 WASHER 40X33.5X1.5 AL 6
28 16630D5TB0 LUBRICATION LINE 1 83 4026359006 WASHER 13.5X18X1.5 AL 4
29 16630D5XB0 LUBRICATION LINE 1 84 4026501008 TAB 12X8X70 1
16630D5WB0 LUBRICATION LINE USA 4026500912 TAB 10X8X70 (USA) 1
30 16630D61B0 LUBRICATION LINE 1 85 4026510032 SEEGER E45 2
31 1673001000 OIL FILTER PLUG 1 86 4026702000 FITTING 6
32 1680609700 OIL PUMP GASKET 1 87 - -
33 1680611600 MANIFOLD GASKET 1 88 4026706000 FITTING 4
34 1680614300 MANIFOLD GASKET 1 89 4026706003 FITTING 2
35 1680707300 FLANGE GASKET 2 90 4026706101 FITTING 2
36 1680700200 FLANGE GASKET 1 91 4026904003 PLUG 1” 6
37 1680709700 GASKET 1 92 - -
38 1680709800 HOUSING GASKET 2 93 4026904300 VENT PLUG ¼” 2
39 16120CJ5B0 OIL DRIPPER FLANGE 1 94 4026904503 PLUG M20X1.5 1
40 1685002800 WASHER 30X8.5X4 1 95 4026905002 PLUG ¼” 2
41 1685100000 WASHER 14X20X1.5 AL 2 96 4026910103 PLUG 1
42 1685100300 WASHER D 20 2 97 4026910601 PLUG 1/8 2
43 16875BHDB0 HOUSING LC300 1 98 16630D5MB0 LUBRICATION LINE 1
44 1687600000 OIL TANK 1 16630D5IB0 LUBRICATION LINE USA 1
45 1691000000 SPRING 1 99 16630D60B0 LUBRICATION LINE 1
46 4022200030 Y-SEAL 41X27X10 1 16630D60B0 LUBRICATION LINE USA 1
47 4022200044 Y-SEAL 65X45X8 1 100 16630D5WB0 LUBRICATION LINE 1
48
4022200416 Y-SEAL 60X75X8 4 16630D5WB0 LUBRICATION LINE USA 1
49 4022300001 OIL FILTER 1
50 4023100047 BEARING 6309 C3 1
51 4023110051 BEARING NU 309 ECJ/C3 1
52 4023250501 RUBER BALL D80 1
