SPARE PART DATA SHEET – ACCESSORIES LC 300
REV
.
10
30-01-2018
29 / 32
Jurop
SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
T
EL
.
+39
0
434
636811
F
AX
.
+39
0
434
636812
http://www.jurop.it
e-mail: info@jurop.it
Accessories LC300
Pos.
Code Description Q.ty Pos.
Code Description Q.ty
3 143028B7B0 PNEUMATIC OPERATED 4-WAY KIT 7 1852108600 FIXED SUCTION CONVEYOR Ø80 KIT
P1 160858KNB0 CONVEYOR 1 C1 1627100300 CONVEYOR Ø80 1
P2 161258B4B0 ACTUATOR SUPPORT 1 C2 4022200307 OR 6287 1
P3 1640580QB0 ACTUATOR COVER 1 C3 4026103002 SCREW M12X30 2
P4 167007ZAB0 CONVEYOR NUT 1 C4 4026350709 WASHER GROWER M12 2
P5 1680700200 FALNGE GASKET 1
P6 168409PQB0 RING NUT 1 8 1852108900 FIXED SUCTION CONVEYOR Ø76 KIT
P7 168529TFB0 SPACER 1 C1 1627100200 CONVEYOR Ø76 1
P8 1691000200 SPRING 1 C2 4022200307 OR 6287 1
P9 4022100100 GREASING NIPPLE M6X1 1 C3 4026103002 SCREW M12X30 2
P10 4022200005 Y-SEAL 37X27X7 1 C4 4026350709 WASHER GROWER M12 2
P11 4022200330 OR 3375 1
P12 4022200331 OR 2137 1 9 1852109000 TURNING CONVAYOR Ø76 KIT
P13 4026102804 SCREW M8X16 4 C5 1610100000 CONVEYOR FLANGE 1
P14 4026102807 SCREW M8X25 4 C6 1627100500 CONVEYOR Ø76 1
P15 4026121405 SCREW M8X20 4 C7 4022200307 OR 6287 1
P16 4026350505 WASHER GROWER M8 4 C8 4026103002 SCREW M12X30 2
P17 4026351505 TOOTHED WASHER M8 8 C9 4026350709 WASHER GROWER M12 2
P18 4027100405 PNEUMATIC ACTUATOR 1
P19 4027421206 FITTING R15 6XG1/8 2 12 18521CNGB0 SUCTION FILTER KIT
4 143029K2B0 HYDRAULIC OPERATED 4-WAY KIT 18920F3XB0 GASKETS KIT LC300 M 1
R1 143027T6B0 HYDRAULIC ACTUATOR 1 18920F3YB0 GASKETS KIT LC300 D 1
R2 150206XXB0 ACTUATOR LEVER 1
R3 151309JVB0 ACTUATOR SUPPORT 1
R4 16240A0IB0 SPACER 1
R5 1624202300 SPACER 1
R6 164206XYB0 PROTECTION 1
R7a 16850A0YB0 WASHER 1
R7b 168509LLB0 WASHER 1
R8 168509U0B0 WASHER 1
R9 4026121407 SCREW M8X25 4
R10 4026121405 SCREW M8X20 2
R11 4026135414 SCREW M8X45 1
R12 4026155705 SCREW M8X16 1
R13 4026308005 NUT M8 4
R14 4026350505 WASHER GROWER M8 6
R15 4026510012 SEEGER E14 7435 1
R16 4022100100 GREASING NIPPLE M6X1 1
R17 1623100800 CONVEYOR FLANGE 1
R18 1680700200 FLANGE GASKET 1
R19 1608503200 CONVEYOR 1
R20 1691000000 SPRING 1
R21 1624027500 SPRING SPACER 1
5 FLANGED MANIFOLD
F1 1627505500 FLANGED MANIFOLD 1
F3 4026350706 WASHER GROWER M8 12
F4 4026102807 SCREW M8X25 12
F5 4026135504 SCREW M10X10 1
6 THREADED MANIFOLD
F2 1627505600 THREADED MANIFOLD 1
F3 4026350706 WASHER GROWER M8 12
F4 4026102807 SCREW M8X25 12
F5 4026135504 SCREW M10X10 1
