SPARE PART DATA SHEET – LC 300-420 M540/1000 HDR
REV
.
10
30-01-2018
23 / 32
Jurop
SpA
Via Crosera n° 50
33082 Azzano Decimo, PN (Italia)
T
EL
.
+39
0
434
636811
F
AX
.
+39
0
434
636812
http://www.jurop.it
e-mail: info@jurop.it
LC 300-420 M540 - M1000 - HDR
Pos.
Code Description Q.ty Pos.
Code Description Q.ty
1 GEARBOX 540 – 1000 RPM 52 4025426209 PULLEY 150X1 SPZ 1
1 4025350019 BELT SPZ 925 1 53 4026102819 SCREW TE 8.8 M8X90 ZINC. 1
2 1407200900 WATER PUMP SX (LC M SX - LC HDR DX) 1 54 4026102908 SCREW TE 8.8 M10X30 ZINC. 1
1407200800 WATER PUMP DX (LC M DX - LC HDR SX) 1 55 4026308006 NUT M10 2
3 1521506800 ROTOR LC300 M 1 56 4026350708 WASHER GROWER M10 P 4
1521505800 ROTOR LC420 M 1 57 4026350706 WASHER GROWER M8 P 21
4 154201TUB0 PROTECTION (LC M SX – HDR DX) 1 58 4026357005 WASHER M8 1
154201TSB0 PROTECTION (LC M DX – HDR SX) 1 59 4026357006 WASHER M10 6
5 1610512900 OIL PUMP SUPPORT 1 2 HYDRAULIC DRIVE
6 1610513500 FLANGE 1 H1 1470102300 JOINT 1
7 1610513600 GEARBOX M 1 H2 1521506700 ROTOR LC300 HDR 1
8 1613501400 OIL PUMP FLANGE 1 1521506000 ROTOR LC420 HDR 1
9 1622002600 SHAFT M10 1 H3 1610513500 FLANGE 2
10 1624037500 SPACER 1 H4 1612501000 BRACKET HDR 1
11 1624037700 SPACER 1 H5 1610021600 FLANGE HDR 1
12 1640501200 GEARBOX FLANGE 1 H6 1624037700 SPACER 1
13 1642100200 REAR PROTECTION 1 H7 1680707300 GASKET 1
14 4029602806 DRIVE SHAFT PROTECTION 1 H8 1680709800 GASKET 1
15 1651005500 PINION Z28 (540 RPM) 1 H9 4022200044 Y-SEAL 65X45X8 1
1651010700 PINION Z42 (1000 RPM) 1 H10 4022200416 Y-SEAL 60X75X8 2
16 1651010500 GEAR Z70 (540 RPM) 1 H11 4024107009 MOTOR LC300 1
1651010600 GEAR Z56 (1000 RPM) 1 4024107001 MOTOR LC420 1
17 1680609700 OIL PUMP GASKET 1 H12 4026101613 SCREW TE 4,8 M12X40 ZINC 2
18 1680614100 GEARBOX GASKET 1 H13 4026136006 SCREW S.TESTA 14.9 M8X14 1
19 1680709800 HOUSING GASKET 2 H14 4026141508 SCREW TE 10.9 M10X30 ZINC. 8
20 1680710000 GASKET 1 H15 4026136003 SCREW S.TESTA 14.9 M8X8 ZINC. 1
21 1681006500 COMP. RING FLANGE 1 H16 4023110051 BEARING NU309 ECJ/C3 2
22 1684000000 PLUG 3/8” 3 H17 4026171211 SCREW PRIGION.8,8 M 12X80 ZINC. 4
23 1685100100 WASHER 10X16X1.5 CU 2 H18 4026121405 SCREW TCEI 8.8 M8X20 ZINC. 3
24 1685100200 WASHER 17X22X1.5 AL 3 H19 4026171304 SCREW PRIGION. 8.8 M14X40 4
25 4022200008 Y-SEAL 90X45X8 1 H20 4026308008 NUT M14 4
26 4022200416 Y-SEAL 60X75X8 4 H21 4026305508 NUT M12 SELFLOCKING 4
27 4022200040 Y-SEAL 72X40X10 1 H22 4026350609 WASHER GROWER M12 P 4
28 4023100039 BEARING 6308 1 H23 4026350610 WASHER GROWER M14 P 4
29 4023100047 BEARING 6309 C3 1 H24 4026351506 WASHER M10 8
30 4023110051 BEARING NU 309 ECJ/C3 1 H25 4026351505 WASHER M8 3
31 4023100020 BEARING 6207 1 H26 4026359001 WASHER 40X33.5X1.5 AL 1
32 4026102804 SCREW TE 8.8 M8X16 ZINC. 3 H27 4026510032 SEEGER E45 1
33 4026102809 SCREW TE 8.8 M8X35 ZINC. 8 H28 4026904003 PLUG 1" 1
34 4026141508 SCREW TE 10.9 M10X30 ZINC. 16 H29 4026501004 TAB 12X8X45 1
35 4024251000 OIL PUMP DX (LC M SX - LC HDR DX) 1
4024251500 OIL PUMP SX (LC M DX - LC HDR SX) 1
36 4026121305 SCREW TCEI 8,8 M6X16 ZINC. 2
37 4026121710 SCREW TCEI 8.8 M12X35 ZINC. 6
38 4026121813 SCREW TCEI 8.8 M10X50 ZINC. 2
39 4026155503 SCREW TSPEI M5X12 5933 ZINC. 4
40 4026300025 COMPENSATION RING 1
41 4026306115 BOLT M36X3 SELFLOCKING 1
42 4026350503 WASHER GROWER M6 Q 6
43 4026350508 WASHER GROWER M12 Q 6
44 4026351506 TOOTHED WASHER M10 15
45 4026351505 TOOTHED WASHER M8 11
46 4026356002 FLAT WASHER 8X24 3
47 4026401806 PIN10X36 2
48 4026501003 TAB 12X8X40 1
49 162403N3B0 SPACER 1
50 161201X4B0 WATER PUMP SUPPORT 1
51 4025426003 BUSHING 1
