JVC AV-2106TE - INITIAL SETTING VALUES

1-16 (No.YA394)
4.7 INITIAL SETTING VALUE OF SERVICE MENU
• Adjustment of the SERVICE MENU is made on the basis of the initial setting values ; however, the new setting values which
set the screen in its optimum condition may differ from the initial setting.
• Do not change the initial Setting Values of the Setting (Adjustment) items not listed in "ADJUSTMENT PROCEDURE".
[2. V/C]
[3. DEFLECTION]
[4.VSM PRESET]
Setting item Variable range
Initial setting value
PAL SECAM NTSC 3.58 NTSC 4.43
1.CUT OFF RED -128 - +127 -50 -50 -50 -50
GREEN -128 - +127 -50 -50 -50 -50
BLUE -128 - +127 -50 -50 -50 -50
2.DRIVE RED -128 - +127 +0 +0 +0 +0
BLUE -128 - +127 +0 +0 +0 +0
3.BRIGHT -128 - +127 +0 +0 +0 +0
4.CONT. -63 - +63+0+0+0+0
5.COLOUR -63 - +63 +0 +0 +0 -5
6.TINT TV -63 - +63 --- --- --- ---
VIDEO -63 - +63 --- --- +0 -1
7.SECAM BL ADJUST -31 - +31 +0 +0 +0 +0
8.SHARP
(Do not adjust)
TV -31 - +31 +8 (Fixed) +8 (Fixed) +8 (Fixed) +8 (Fixed)
VIDEO -31 - +31 +15 (Fixed) +15 (Fixed) +15 (Fixed) +15 (Fixed)
9.AMP T. SHARP -31 - +31 -12 -12 -12 -12
Setting item Variable range
Initial setting value
fv : 50Hz fv : 60Hz
1. VER. POSITION -4 - +3 -1 -3
2. HOR. POSITION -16 - +15 +3 +3
3. VER. HEIGHT -64 - +63 -35 +1
4. VER. LINEARITY -32 - +31 +15 -1
5. VER. SCURVE -32 - +31 -32 +0
6. HOR. VCO ADJUST [Do not adjust] -63 - +63 +0 +0
Setting item Variable range
Initial setting value
BRIGHT STANDARD SOFT
TINT 0 - 30 15 15 15
COLOUR 0 - 30 15 15 15
BRIGHT 0 - 30 15 15 15
CONT. 0 - 30 30 18 14
SHARP 0 - 30 20 15 12
