(No.YA394)1-17
[5. PRESET]
The items in the following table, it is no requirement for adjustment.If values had changed by the miss operation, set the
initial setting values in the following table.
z COLOUR SYSTEM (Do not adjust)
z SOUND SYSTEM (Do not adjust)
Setting item Variable range
Initial setting value (Fixed value)
PAL SECAM NTSC 3.58 NTSC 4.43
1. C TRAP FIX 0 - 1 1 1 1 1
2. SHARP PEAK 0 - 1 0 0 0 0
3. ABL 0 - 11111
4. GAMMA 0 - 1 0 0 0 0
5. Y. DELAY TIME TV 0 - 3 0 2 2 3
VIDEO 0 - 30202
6. BLACK EXP START 0 - 3 3 3 3 3
7. C-BPFTV 0 - 11100
VIDEO 0 - 11111
8. CW / SCP 0 - 1 0 0 0 0
9. VIF DET LEVEL -63 - +63 +0 +0 +0 +0
11. IF AGC MIN 0 - 1 0 0 0 0
12. VIF AGC 0 - 1 0 0 0 0
13. VIF PMOD 0 - 1 0 0 0 0
19. VNR 0 - 63 15 15 15 15
20. RGB LIM 0 - 1 1 1 1 1
21. RGB LIMIT LEVEL 0 - 7 2 2 2 2
23. TEXT H. POSITION -16 - +15 -3 -3 -3 -3
24. READ DATA --- --- --- --- ---
Setting item Variable range
Initial setting value (Fixed value)
B/G I D/K M
10. SIF DET LEVEL -7 - +7 +0 +0 +0 +0
14. SIF BPF BW ADJUST -7 - +7 +0 +0 +0 +0
15. SIF TRAP FO ADJUST -7 - +7 +0 +0 +0 +0
16. SIF TRAP FO ADJUST 2 -7 - +7 +0 +0 +0 +0
17. SIF -TRAP 0 - 10000
18. SIF -BPF 0 - 10001
22. SIF SW 0 - 11110
