AV-27D502
32 No. 51797
CONTENTS
USING P.W. BOARD & REMOTE CONTROL UNIT ................................................................................. 32
EXPLODED VIEW PARTS LIST ............................................................................................................... 32
EXPLODED VIEW .................................................................................................................................... 33
PRINTED WIRING BOARD PARTS LIST (AV-27D502/R)
MAIN PW BOARD ASS'Y .....................................................................................................................................34
CRT SOCKET PW BOARD ASS’Y .......................................................................................................................37
FRONT CONTROL PW BOARD ASS’Y ...............................................................................................................37
FRONT AV INPUT PW BOARD ASS’Y .................................................................................................................37
LF PW BOARD ASS’Y ..........................................................................................................................................38
PIP PW BOARD ASS’Y.........................................................................................................................................38
AV SELECTOR PW BOARD ASS’Y .....................................................................................................................38
REMOTE CONTROL UNIT PARTS LIST (RM-C301G-2A).............................................................................. 40
DIFFRENCE PARTS LIST BETWEEN AV-27D502/R AND AV-27D502/S .......................................................41
PACKING / PACKING PARTS LIST .....................................................................................................................42
EXPLODED VIEW PARTS LIST
!
Ref.No. Part No. Part Name Description Local
! L01 CE41329-00DJB DEG COIL
! T1502 QQH0092-001 FBT Within MAIN PWB
! V01 A68ADT25X01 CRT Inc. DY(AV-27D502/R)
! V01 A68QDN891X001 CRT Inc. DY(AV-27D502/S)
! 1 QMPD200-200-JC POWER CORD CN90PW Within LF PWB
2 LC30191-002A-A REMOCON WINDOW
3 CM48006-007-C JVC MARK
4 LC20217-005A-A CONTROL KNOB
5 A48457-4-S SPRING
6 WJY0016-001A BRAIDED WIRE
7 WJY0013-004A BRAIDED WIRE
! 8 CEBSS12D-04KJ2 SPEAKER (x2) SP01, SP02
! 9 LC10883-001C-A CHASSIS BASE
! 10 LC20626-003D-A TERMINAL BOARD
11 QYSBSB3010Z TAPPING SCREW (x4)
12 CHGY0031-0C ANT CABLE ASSY
! 13 LC10277-003A-A REAR COVER
14 QYSBSFG4016Z TAPPING SCREW (x12)
15 LC30684-005A-A BBE LABEL
! 16 LC31139-001A-A RATING LABEL
! 17 LC20106-001D-A CORD CLAMP
18 QYSBSB4012Z TAPPING SCREW (x8)
! 100 LC10964-002A-A FRONT CABI ASSY Inc. No. 101-102
101 LC20409-005A-A DOOR
102 CM48229-00A-C DOOR LATCH
USING P.W. BOARD & REMOTE CONTROL UNIT
MAIN PW BOARD SAC-1507A-M2 SAC-1506A-M2
CRT SOCKET PW BOARD SAC-3507A-M2 SAC-3506A-M2
FRONT CONTROL PW BOARD SAC-8502A-M2
FRONT AV INPUT PW BOARD SAC-8602A-M2
LF PW BOARD SAC-9503A-M2
PIP PW BOARD SAC0P502A-M2
AV SELECTOR PW BOARD SAC0S504A-M2
REMOTE CONTROL UNIT RM-C301G-2A
AV-27D502/R AV-27D502/S
P.W.B ASS’Y
Model
To Next Page
