! Symbol No. Part No. Part Name Description Local ! Symbol No. Part No. Part Name Description Local
AV-27D502
38 No. 51797
RESISTOR
R9997 QRE121J-5R6Y C R 5.6Ø 1/2W J
! R9998 QRZ9041-275 C R 2.7MØ 1/2W K
CAPACITOR
! C9901 QFZ9067-104 MM CAP. 0.1µF
! C9902 QFZ9067-473 MM CAP. 0.047µF
! C9904 QCZ9052-102 C CAP. 1000pF
OTHERS
! CN90PW QMPD200-200-JC POWER CORD
! F9901 QMF0007-5R0J1 FUSE 5A
FC9901 CEMG002-001Z FUSE CLIP
! LF9902 QQR0527-003 LINE FILTER
! VA9901 ERZV10V621CS VARISTOR
PIP PW BOARD ASS'Y (SAC0P502A-M2)
! Symbol No. Part No. Part Name Description Local
RESISTOR
R0001-02 NRSA63J-103X MG R 10kØ 1/16W J
R0003-04 NRSA63J-101X MG R 100Ø 1/16W J
R0005 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0011 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0121 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0301 NRSA63J-473X MG R 47kØ 1/16W J
R0303 NRSA63J-222X MG R 2.2kØ 1/16W J
R0304 NRSA63J-473X MG R 47kØ 1/16W J
R0306 NRSA63J-222X MG R 2.2kØ 1/16W J
R0307-08 NRSA63J-332X MG R 3.3kØ 1/16W J
R0309 NRSA63J-102X MG R 1kØ 1/16W J
R0311 NRSA63J-101X MG R 100Ø 1/16W J
R0313 NRSA63J-101X MG R 100Ø 1/16W J
R0314 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0316 NRSA63J-331X MG R 330Ø 1/16W J
R0317 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0331 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0337 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0343 NRSA63J-0R0X MG R 0.0Ø 1/16W J
CAPACITOR
C0003-04 QETN1HM-106Z E CAP. 10µF 50V M
C0006 QETN1HM-106Z E CAP. 10µF 50V M
C0008 QETN1EM-476Z E CAP. 47µF 25V M
C0301-02 NRSA63J-0R0X MG R 0.0Ø 1/16W J
C0312-13 NDC31HJ-270X C CAP. 27pF 50V J
C0314 QETN1HM-106Z E CAP. 10µF 50V M
C0315 NCB31HK-103X C CAP. 0.01µF 50V K
C0316-18 NCB21HK-104X C CAP. 0.1µF 50V K
C0319 QETN1HM-106Z E CAP. 10µF 50V M
C0320 NCB31HK-103X C CAP. 0.01µF 50V K
C0321 QETN1HM-105Z E CAP. 1µF 50V M
C0322 NCB31HK-103X C CAP. 0.01µF 50V K
C0323 QETN1HM-106Z E CAP. 10µF 50V M
C0324-25 NCB31HK-103X C CAP. 0.01µF 50V K
C0326 NCB21HK-104X C CAP. 0.1µF 50V K
C0327 QETN1HM-225Z E CAP. 2.2µF 50V M
C0328 NCB31HK-103X C CAP. 0.01µF 50V K
C0329 QETN1HM-225Z E CAP. 2.2µF 50V M
CAPACITOR
C0330 NCB31HK-103X C CAP. 0.01µF 50V K
C0331 NCB21HK-104X C CAP. 0.1µF 50V K
COIL
L0302-04 QQL244J-6R8Z COIL 6.8µH J
DIODE
D0301 1SS133-T2 SI.DIODE
TRANSISTOR
Q0301-03 2SC2412K/QR/-X SI.TRANSISTOR
IC
IC0001 AN7805F I.C.(MONO-ANA)
IC0301 SDA9389X-X I.C.(DIGI-MOS)
OTHERS
! TU0001 QAU0206-001 TUNER
X0301 QAX0521-001Z CRYSTAL
AV SELECTOR PW BOARD ASS'Y (SAC0S504A-M2)
! Symbol No. Part No. Part Name Description Local
RESISTOR
R0081 NRSA63J-102X MG R 1kØ 1/16W J
R0082 NRSA63J-682X MG R 6.8kØ 1/16W J
R0083 NRSA63J-153X MG R 15kØ 1/16W J
R0084 NRSA63J-683X MG R 68kØ 1/16W J
R0085 NRSA63J-332X MG R 3.3kØ 1/16W J
R0086 NRSA63J-333X MG R 33kØ 1/16W J
R0087 NRSA63J-153X MG R 15kØ 1/16W J
R0088 NRSA63J-152X MG R 1.5kØ 1/16W J
R0089 NRSA63J-562X MG R 5.6kØ 1/16W J
R0090 NRSA63J-563X MG R 56kØ 1/16W J
R0151-54 NRSA63J-223X MG R 22kØ 1/16W J
R0155 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0157 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0159 NRSA63J-103X MG R 10kØ 1/16W J
R0202 NRSA63J-101X MG R 100Ø 1/16W J
R0210 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0211 NRSA63J-153X MG R 15kØ 1/16W J
R0212 NRSA63J-333X MG R 33kØ 1/16W J
R0213 NRSA63J-102X MG R 1kØ 1/16W J
R0214 NRSA63J-181X MG R 180Ø 1/16W J
R0215 NRSA63J-152X MG R 1.5kØ 1/16W J
R0216 NRSA63J-182X MG R 1.8kØ 1/16W J
R0217 NRSA63J-102X MG R 1kØ 1/16W J
R0218 NRSA63J-222X MG R 2.2kØ 1/16W J
R0223 NRSA63J-0R0X MG R 0.0Ø 1/16W J
R0229 NRSA63J-473X MG R 47kØ 1/16W J
R0230 NRSA63J-223X MG R 22kØ 1/16W J
R0231 NRSA63J-101X MG R 100Ø 1/16W J
R0232 NRSA63J-102X MG R 1kØ 1/16W J
R0233 NRSA63J-272X MG R 2.7kØ 1/16W J
R0234 NRSA63J-102X MG R 1kØ 1/16W J
R0235-36 NRSA63J-101X MG R 100Ø 1/16W J
R0238 NRSA63J-822X MG R 8.2kØ 1/16W J
R0239 NRSA63J-123X MG R 12kØ 1/16W J
LF PW BOARD ASS'Y (SAC-9503A-M2)
