JVC CL-S500 Series - Page 28

- 28 -
External dimensions
for single screen
Portrait (vertical orientation)
361. 5
89.8
〜
184.8
339
493
422.5
270.5
〜
365.5
361. 5
339
240
422.5
493
24
〜
119
11.5
166.5
80.5
34.5
-5
°
196.5
270.5
〜
365.5
4.3
+20
°
95
Landscape (horizontal orientation)
Unit: mm
