JVC CL-S500 Series User Manual

- 27 -
Technical specication
Item
CL-S500BG0UA, CL-S500BG0EA,
CL-S500BG2UA, CL-S500BG2EA for single screen
LCD 21.3-inch (54 cm), color, TFT, Anti-glare, IPS
Pixel pitch (H × V) 0.165 × 0.165 mm
Display area (H × V) 337.92 × 422.4 mm (Portrait)
Pixel (H × V) 2048 × 2560 (Portrait)
Display colors
8 bit: 16.77 million
10 bit: 1.073 billion
Backlight LED backlight
LCD Optical
characteristics (typ.)
Viewing angle: 178 ° horizontal and vertical (Contrast ratio ≥ 50:1)
Contrast ratio: 2000:1 (Viewing angle of 0 ° horizontal and vertical)
Maximum luminance: 1150 cd/m
2
Input sync signal DVI 1.0 compliant, DisplayPort 1.2a compliant
Available resolution
VGA–XGA
2048 × 2560 (at Fv=25/50 Hz), 2560 × 2048 (at Fv=25/50 Hz)
Input terminal DVI 24-pin connector, DisplayPort IN connector
Output terminal DisplayPort OUT connector
USB Hub
USB Rev. 2.0 compliant, Self-powered,
USB upstream port (×1), USB downstream ports (×2)
Environmental
Conditions
Operating Transport/Storage
Temperature: 5 to 35 °C* -20 to 60 °C
(41 to 95 °F* -4 to 140 °F)
Humidity (no condensation): 30 to 80 % 10 to 85 %**
Air pressure: 700 to 1060 hPa 266 to 1060 hPa
* Operating temperature range that ensures optimal performance
of the monitor is 20 to 30 °C (68 to 86 °F).
** Wet-bulb temperature Max. 38 °C (100.4 °F) [Ta>40 °C (104 °F)]
The monitor installed on desk in observation room or diagnostic
reading room.
The ambient light in the room should be less than 29.3 lx.
Power 100–240 V
2.2–1.1 A 50/60 Hz
Dimensions
(W × H × D)
for single screen
Net: 361.5 × 517.0–612.0 × 196.5 mm (Portrait)
493.0 × 451.3–546.3 × 196.5 mm (Landscape)
Packed: 585.0 × 580.0 × 285.0 mm
Weight (approx.)
for single screen
Net: 9.5 kg (Without stand 6.5 kg),
Packed: 12.5 kg
Calibration kit
(Optional)
Calibration sensor and software
Conformities
ANSI/AAMI ES60601-1 (2005)+A1 (2012),
CAN/CSA-C22.2 No.60601-1 (2014), FCC-B, ICES-003-B, FDA510(k),
CE, UKCA, RCM, VCCI-B, RoHS
Specications are subject to change without notice.
