Design and specifications are subject to change without notice.
SPECIFICATIONS
Ty p e Active Subwoofer System (Built-in amplifier)
Speaker Unit 30 cm (11-13/16 inch) cone
Input Terminal LINE IN (1 system), 0.18 V – 4 V
SPEAKER (1 system), 3.9 V – 12 V
Maximum Amplifier Power Output 350 W
Cut-off Frequency 50 Hz – 300 Hz (b12 dB/oct. low pass filter)
Sound Pressure Level 110 dB/ m (with line input: 0.03 V)
Level Control b50 dB to a 6 dB
Center: 0 dB
Power Requirement DC 14.4 V (11 V to 16 V allowance)
Negative ground
Mass 18.8 kg (42 lbs) (Excluding accessories)
SUPPLIED ACCESSORIES
Speaker input connector 4P 200 mm (7-7/8 inch) c 1 (Including cord)
Stay c 4
Tapping screw ø4 mm c 16 mm (Dia. 3/16 inch c 21/32 inch) c 8
Insulation tape c 1
