2
Preparation
20
Connecting(Continued)
SYNC
B RG
SYNC
S-VIDEO
VIDEO
RS-232C
HDMI 1
HDMI 2
Y
C
B/PB
CR/PR
TRIGGER
●
Do not supply the power to the other devices.
●
Do not connect audio terminals of the other devices such as
headphones etc. Otherwise, this may cause a malfunction of
the other devices or injury.
●
Using beyond the rated value will cause malfunction.
●
Exercise adequate caution to prevent short circuit as the trigger
terminal outputs a voltage of 12V.
Screen
Connecting via Trigger Cable
CAUTION
Trigger cable
(sold separately)
To Trigger output terminal
This unit
Trigger input terminal
(Φ3.5)
To Next Page
