Getting started
Main body - Rear
Controls and features (continued)
㽹 Input terminal
There is also a terminal other than the input
terminal for video images, such as those used
for controlling or optional equipment. Please see
“
A
bout input terminals
”
for detailed information
about terminals. (Reference page: 19
㽺 Lamp Cover
When replacing the light source lamp, remove
this cover. (Reference page: 78
㽻 Operation panel
See the following illustration
“
Control panel
”
for
more details.
㽼 Light receiving section of the
remote control (rear)
Please aim the remote control at this section
when using.
(* There is also a light receiving section at
the rear.
㽽 Power input terminal
This is the power input terminal. It is
connected via the supplied power cord.
(Reference page: 34
To
turn on/off the power
To
switch input
7RVHOHFWRUFRQ¿UP
Up button
Right button
Left button
Down button
To
display the menu
To
return to the previous menu
STANDBY/ON
MENU
BACK
INPUT
OK
㽶 Inlets
㽺 Lamp Cover
㽻 Operation panel
㽽 Power input
terminal
㽹 I
nput
terminal
㽶 Inlets
㽼 L
ight receiving section
of the remote control (rear)
■
O
peration panel
