JVC DLA-X90R

Operation
67
ENGLISH
Adjust Color
Use this function to set the color of the pixels you want to adjust.
Settings: Red, Blue [Red]
Adjust Pattern Color
Use this function to set the adjust pattern color. Set according to your preference.
Settings: White, Green + (Adjust Color) [White]
White Use this function to set the Adjust pattern to white.
Green +
(Adjust Color)
Use this function to set the Adjust pattern to green and the color set using [Adjust Color]
items.
Adjust(Pixel)
Use this function to move the color selected using the [Adjust Color] items for the pixels
on the entire screen pixel by pixel in the vertical and horizontal directions.
(*) This function cannot be used when the [Adjust Area] is set to [Zone].
H (Horizontal) settings: -2 ~ 2 [0]
V (Vertical) settings: -2 ~ 2 [0]
Adjust(Fine)
Use this function to move the color selected using the [Adjust Color] items for the pixels
on the entire screen pixel by pixel in the vertical and horizontal directions.
H (Horizontal) settings: -31 ~ 31 [0]
V (Vertical) settings: -31 ~ 31 [0]
Reset
Setting all pixel adjust data to default factory settings.
[3-2] Pixel Adjust
30
Use this function to adjust color errors on the horizontal and vertical
directions of the video images.
Use the UP/DOWN keys to select an adjustment item. Press the
[BACK] key to return to the previous screen.
(*) It is impossible to match all image pixels on the screen. Due to the
equipment, there will always be some gaps. Color errors vary depending on
screen position.
(*) In case the image is reversed, or upside-down, the horizontal and vertical
directions are reversed.
(*) Please perform adjustments on a clear still picture.
)RU¿QHWXQLQJWKHHIIHFWVRIDGMXVWPHQWVPD\EHGLI¿FXOWWRXQGHUVWDQGIRUVRPHYLGHRLPDJHV
Items Explanation, operation, precautions, settings
Horiz. Red
Horiz. Blue
(Move red to the left) 1 to 5 (move red to the right) [3]
(Move blue to the left) 1 to 5 (move red to the right) [3]
Vert. Red
Vert. Blue
(move red down) 1 to 5 (move red up) [3]
(move blue down) 1 to 5 (move blue up) [3]
Horiz. Blue
Pixel Adjust
Vert. Red
Vert. Blue
3
3
3
Horiz. Red
3
Adjustments and settings in the menu (continued)
