Masterpage:Right+
EN 55
Filename [DR-MV1SE_07VCR Operation.fm]
Page 55 March 11, 2004 7:27 pm
OPERATIONS ON VCR DECK
You can programme this unit to timer-record as many as
8 programmes.
If you do not know the S
HOWVIEW number for the programme you
wish to record, use the following procedure to set your unit to
timer-record the programme.
1 Load a cassette with the record safety tab intact.
2 Press VCR/DVD repeatedly so that the VCR lamp lights up on
the unit.
3 Press PROG/CHECK to access the
Programme Check screen.
4 Press rt to select the blank
number, then press ENTER. The
programme screen appears.
5 Press we to select “START”, then
press rt to set the desired start time.
Each press of rt advances/goes
back the start time in 1-min.
increments.
To advance/go back the start time in
30-min. increments, press and hold
rt.
6 Press we to select “STOP”, then press rt to set the desired
stop time.
Each press of rt advances/goes back the stop time in 1-min.
increments.
To advance/go back the stop time in 30-min. increments, press and
hold rt.
7 Press we to select “DATE”, then press rt to set the desired
date.
The current date appears on the TV screen. The date you enter
appears in its place.
8 Press we to select “TV PROG”, then press rt to select the
desired channel.
9 Press REC MODE to select the desired recording mode. Or
press we to select “SP/EP”, then press rt to select the desired
recording mode.
10 Press ENTER to access the Programme Check screen.
11 Press PROG/CHECK to complete timer programming.
“PROGRAM COMPLETED” appears on the TV screen for about 5
seconds, then the normal screen appears. If “PROGRAM
OVERLAP” appears on the TV screen, see page 56.
To programme another timer, repeat steps 3 11.
12 Press VCR TIMER (#) to engage the unit’s timer mode. The
VCR timer lamp lights up on the unit and the DVD deck is
automatically selected. When the DVD deck is in timer standby
mode, the unit is automatically turned off.
To disengage the timer mode, press VCR TIMER (#) again.
NOTES:
To Timer-Record Weekly Or Daily Serials:
anytime during steps 7 through 9, press number key “9” for
weekly serials or number key “8” for daily serials (Monday – Friday).
Either “WEEKLY” or “DAILY” appears on the TV screen. Pressing the
button again makes the corresponding indication disappear.
You can programme this unit to timer-record as many as 8
programmes. If you try to programme the unit to record a ninth,
“PROGRAMME FULL” appears on the TV screen. To record the extra
programme, you must first cancel any unnecessary programmes.
(
pg. 56)
In case of a power failure after programming, the unit’s memory
backup keeps your selections for approximately 5 seconds.
Programmes that start after midnight must have the next day’s date.
To record the programmes received by satellite receiver, record on
the DVD discs. For details, refer to “Manual Timer Programming”
(
pg. 44).
VPS/PDC Recording
Now available from some TV stations, PDC (Programme Delivery
Control) and VPS (Video Programme System) are services
designed to assure safe, accurate timer recording. With this
system, special code signals are transmitted together with the
audio/video signals. These code signals control your video unit and
have precedence over the advertised times you may have preset
into the timer. This means that your unit will start and stop
recording when the preset TV programmes actually start and end
— even if the broadcast time of a preset TV programme is
changed.
NOTES:
When you use Manual Timer Programming, set the start time (VPS
or PDC time) exactly as advertised in the TV listing. A different time
than advertised will result in no recording.
VPS/PDC recording is also possible when a satellite receiver or a
cable system is connected to L-2 IN/DECODER connector on your
unit.
VPS/PDC recording is also possible via the L-1 IN/OUT connector.
How to check if the station being received transmits a VPS/
PDC signal
A Hold down DISPLAY for about 5 seconds. “VPS/PDC” appears
blinking on the front display panel. If a VPS/PDC signal is detected
from the station, “VPS/PDC” will stop blinking. If no VPS/PDC
signal is detected from the station, “VPS/PDC” will blink at a slower
rate.
B Press DISPLAY again to return to normal display.
Manual Timer Programming
Make sure that the units built-in clock is set properly.
Turn on the unit.
Turn on the TV and select the AV mode.
Slide the TV/CABLE/SAT/DVD switch to DVD.
1
4
7
2
5
8
0
3
6
9
PROG/CHECK
ENTER
VCR TIMER (#)
rtw e
VCR/DVD
0 – 9
REC MODE
SAT
DR-MV1SE_00.book Page 55 Thursday, March 11, 2004 7:28 PM
