ENGLISH
6
Detaching/attaching the monitor panel While the unit is turned on:
Detaching
1
Detach?Yes No
* You can also use OPEN on the monitor panel.
Then press [Detach].
The monitor panel opens by about 50°.
• It closes automatically when no operation is done
for about a minute.
2
The monitor panel is unlocked. • The attaching plate closes automatically about
10 seconds after the monitor panel is released.
3
Remove the monitor panel before this happens.
Attaching
*
Attaching plate
Caution:
• Hold the monitor panel securely so
as not to drop it accidentally.
• Fit the monitor panel onto the
attaching plate until it is firmly
Soft case
locked.
(supplied)
